SolutionsPET Preform System

In the PET preform system, drying material is an essential step in the material process, which must be taken correctly. The moisture in the material must be dried at the exact drying temperature, dew point, time, and other relevant conditions. Shini understands the process and offers standard and energy-saving dehumidifying dryer that caters to the industry.
PET Preform System
Based on its technology strength and experience in auxiliary equipment field, Shini can meet various kinds of demands from plastics conveying, dehumidifying and drying; mould heating and cooling; regrinds recycling to color management. Adopt intelligent energy-saving control technology to monitor the material processing, Shini can provide different solutions according to different requirements from the customers.

Auto Conveying & Feeding System

All material contact surfaces and filter device of the Plastics Material Handling Systems are made of stainless steel ensures no contamination during PET material conveying.

By adjusting conveying speed, the flexible air refilling adjusting system can avoid stringing and dusting caused by different conveying situations.

For high temperature conveying of PET, Shini specially came up with the solution with water-cooling function which decrease the risk of high temperature material conveying.

Closed loop of two-stage conveying system. For the conveying of materials to the hopper on injection molding machine, Shini can greatly reduce the heat dissipation and the risk of material rewetting.

Drying System

In PET preform system, drying becomes the most critical step which must be seriously taken and the moisture in the material must be removed at a reasonable temperature.

Shini dehumidifying dryer can provide dew-point of -40℃ or even lower. Also it can achieve constant detection of all the parameters and stabilize the dew-point.

Dew-point of traditional dehumidifiers can not be set and the machines are working full-loaded. However, the humidity requirements of PET material processing are always rigorous. Therefore, the dew-point must be set and controlled properly. Differ from traditional dehumidifier, the new Shini model combines the settable dew-point together with the regenerating control greatly saves the energy.

Color Management System

SCM model of Shini is suitable for masterbatch particles both crystallized and non-crystallized with output within 0.2~32
kg/hr. If the masterbatch proportion and precision is demanding, SGD model is suggested which adopt loss-in-weight calculation with output within 0.04~32kg/hr.

The inner cooling water system can prevent masterbatch from falling into the PET main stream and melting. Thus ensures accurate dosage. Molding cycles of adding masterbatch can be set to meet the requirements of micro weight measuring.

PET Crystallizer

Shini PET crystallizer is specially designed for the homogeneous crystallization as well overcoming glass transition temperature. Also it can avoid material bonding and bridging. With models from SCR-160U to SCR-1600U, the hopper capacity ranges from 160 to 1,600 liters.

The material level switch can help adjust the running mode of both the crystallizer and the feeding device based on the actual material level it detects. Adopt accurate temperature detection system and rotary valve equipped at the material discharge port to ensure constant crystallization and avoid material degradation.

Gravimetric Blender

With gravimetric sensor and material level switch, the special gravimetric blender designed for high temperature material is suitable for PET crystallized materials.

Ethernet interface attached to the controller works together with the relevant software, material proportion data (max. output, actual output, proportioning accuracy) can be transmitted to control product quality. Recalibration will be automatically started after each weighing to ensure optimal proportion accuracy. Regrinds auto compensation function available. Aberration compensation can be automatically calculated based on the discharge amount of material.

Special bridge-breaking structure and discharge way are used to meet all the requirement of sheet material dosing and at the same time ensure the continuity of the operation.

Mould Sweat Dehumidifying System

When mould surface temperature is lower than the surrounding air dew-point temperature, dew will emerge. The formation of dew will not only lead to poor product quality and reduction of productivity, also the mould surface can be corroded in succession pollute the environment. Shini mould dehumidifier can effectively solve the problem and ensure stable molding condition and maximum production capability of PET system.

Cooling System

The chiller of Shini can provide accuracy control of temperature, flow and pressure, cooling effects can be played to the limit. Chillers can be divides into two types, water-cooled and air-cooled. There are other parts of the cooling system, such as cooling tower, pump and water tank. Based on the standard equipment and technology, Shini can come up with individual solutions to meet different kinds of requirements.

On-line PET Water Ratio Detection

In PET molding production, water contains play a very important role in the production. To ensure high quality, the water ratio of the PET material must be controlled within the range permitted. AQU 100 water contain tester is dedicated to detect PET material.
